Vision Console

true analog console. designed for surround.

The only analog console ever designed from the ground up for surround work. A new Surround Sound mixing and recording console, featuring surround assign and panning on each fader, plus comprehensive central facilities.

Vision Console features

Resettable Switch Automation, assignable per Channel or Globally

Resettable Bus Assign, assignable per Channel or Globally

Dedicated 5.1 Mix Bus

Moving Faders

Two 100mm Automated Faders on each Channel

Simultaneous Surround and Stereo Mixing

all Vision features

Each Channel Features
- Dual Input
- Two 100mm Moving Faders on each Input
- 5 Channel Surround Panning on each Fader
- Dedicated 5.1 Mix Bus
- 3 Stereo Buses
- 24 Main Buses
- 10 Aux sends
- Sweep Filter
- Choice of Equalizers (550L 4-band or 560L 10-band Graphic)
- Optional dynamics includes the 225L Compressor and 235L Noise Gate
Provision for optional signal processing

215L Sweep Filter
205 Direct Input
212L Mic Pre
225L Compressor
235L Noise Gate
Central Facilities
- Comprehensive Surround Monitoring
- 8 Multi-channel Playback selectors
- Bass Management
- Individual Solo/Mute control of surround monitors
- Surround Fold Down Matrix
- Central Computer/monitor for Automation and Switch Control
- Machine Control
- Monitor Calibration Controls
- 3 sets of speaker assigns
